Speed Graphic

Speed Graphic


Serial Number: Cam0165

Type:
Press Camera

Manufacturer:
Graflex, Rochester, New York

Country of Origin:
United States of America

Production Period:
1912 until 1973

Approximate Price:
USD 550.000

Reference:
Camerapedia

Status: Display

Description:
The speed graphic is produced by Graflex in Rochester, New York and is commonly called the most famous press camera. Although, the first speed graphic cameras were produced in 1912, production of the later versions continued until 1973. It was a standard equipment for many American press photographers until the mid 1960s.

Despite the common appellation of Speed Graphic, various Graphic models were produced between 1912 and 1973. The authentic Speed Graphic has a focal plane shutter that the Crown Graphic and Century Graphic models lack. The eponymous name "speed" came from the maximum speed of 1/1000 sec. that could be achieved with the focal plane shutter. The Speed Graphic was available in 2¼ x 3¼ inch, 3¼ x 4¼ inch, 5 x 7 inch and the most common format 4 x 5 inch. Because of the focal plane shutter, the Speed Graphic can also use lenses that do not have shutters (known as barrel lenses).

The Speed Graphic was a slow camera. Setting the focal plane shutter speed required selecting both a slit width and a spring tension. Each exposure required the photographer to change the film holder, open the lens shutter, cock the focal plane shutter, remove the dark slide from the inserted film holder, focus the camera, [a] and release the focal plane shutter. Conversely, if the lens shutter were used, the focal plane shutter (on the Speed Graphic and Pacemaker Graphic models with both shutters) had to be opened prior to cocking using the "T" or TIME setting, and then releasing the shutter in the lens. If indoors, the photographer also had to change the flashbulb. Each film holder contained one or two pieces of sheet film which had to be loaded into the film holder in complete darkness. Faster shooting could be achieved with the Grafmatic film holder, which is a six sheet film "changer" that holds each sheet in a septum. Even faster exposures could be taken if the photographer was shooting film packs of 12 exposures, or later 16 exposures (discontinued in the late 1970s). With film packs one could shoot as fast as one could pull the tab and cock the shutter, and film packs could be loaded in daylight. A roll film adapter that used 120 or 220 film was available for 2.25 x 3.25, 3.25 x 4.25 and 4 x 5 inch cameras that permitted 8 to 20 exposures per roll, depending on the model of the adapter. Photographers had to be conservative and anticipate when the action was about to take place to take the right picture. The cry, "Just one more!" if a shot was missed was common. President Harry Truman introduced the White House photographers as the "Just One More Club."
